JN-1685B is a professional top-loading CIS multi-currency value counter supporting up to 14 currencies. It features mixed denomination counting, counterfeit detection via UV/MG/MT/2×CIS, and serial number scanning for USD and EUR.
| Item | Specification |
|---|---|
| Hopper Capacity | 300 notes |
| Stacker Capacity | 200 notes |
| Counting Speed | 800 / 1000 / 1200 pcs/min |
| Banknote Size | Length: 110–185 mm / Width: 50–85 mm |
| Detection | UV, MG, MT, Dual CIS |
| Serial Number | USD & EUR |
| Display | TFT Color Screen |
| Interface | USB, RS232 |
| Supported Currencies | Up to 14 |
| Power Supply | AC 90–240V, 50–60Hz |
| Power Consumption | 60W |
| Product Size | 253 × 292 × 275 mm |
| Net Weight | ~6 kg |
| Item | Specification |
|---|---|
| Net Weight | 5.9 – 6.2 kg |
| Gross Weight | 15 kg (2 units/carton) |
| Color Box Size | 338 × 307 × 270 mm |
| Master Carton Size | 635 × 350 × 290 mm |
Enables single denomination sorting and alerts when a different denomination is detected, with continuous fake note checking
Provides high-speed piece counting mode without counterfeit detection for bulk cash processing
Integrates dual CIS image recognition with UV, MG, and MT detection to identify counterfeit, damaged, or suspicious banknotes
Supports serial number scanning for the majorcurrencies, selectable via front panel control
Offers adjustable counting speeds of 800, 1000, and 1200 notes per minute, depending on the selected mode
Allows manual or automatic start operation to match different workflow requirements
Includes the ADD function for cumulative counting across multiple batches
Supports batch counting with numeric keypad input and a quick reset function
Displays detailed counting reports on screen and supports printing in mixed denomination mode
The counter can accommodate up to 14 currency types
Features a TFT color display with an intuitive front-panel control layout
Equipped with USB and RS232 interfaces for data communication and software upgrades
Designed with a top-loading structure for stable feeding and easy maintenance
Operate in a clean indoor environment, away from strong light and electromagnetic interference.
Keep rollers free from oil or grease to ensure accurate counting.
Clean feeding and transport paths weekly, especially optical components.
Ensure all covers and locks are properly secured after maintenance.
Insert USB flash drive with upgrade files in the root directory.
Power on the machine, then power off.
Remove the USB drive and restart to complete the upgrade.
